BEVERAGE PUMP RANGE

INNOVATING PUMPS FOR THE BEVERAGE INDUSTRY

ROTARY DIAPHRAGM PUMPS

PERFORMANCE OVERVIEW

FLOW

0.06 - 1.32 G/MIN

DOWN TO 300 MBAR ABS

VACUUM

WHY CHOOSE ROTARY DIAPHRAGM?

The patented rotary diaphragm technology has a revolutionary pumping principle. The flow is initiated by an eccentrically mounted bearing on a drive shaft which revolves within a flexible diaphragm. As the shaft rotates, the bearing flexes the diaphragm, squeezing liquid through the pump.

PRESSURE

UP TO 2 BAR

Unique features of a rotary diaphragm pump
Unique features of a rotary diaphragm pump
Unique features of a rotary diaphragm pump


RD01

Asset 1 (1).png

FEATURES

• Max Flow : 0.06 G/min

• Max Lift : 3.28ft

• Max Head : 3.28ft

• Size : 3.4" x 2.1" x 2.5"

• Connector Size : 0.3" OD

MATERIALS

Diaphragm : SARLINK

Head : POLYPROPYLENE

• 110V • 50/60Hz

• 230V

PERFORMANCE

RD01 Graph.jpg

RD1

Asset 1 (1).png


FEATURES

• Max Flow : 0.22 G/min

• Max Vacuum : 300 mbar

• Max Pressure : 2.0 bar

• Size : 1.7" x 4.9" x 2.4"

• Connector Size : 0.3" OD

MATERIALS

Diaphragm: SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

PERFORMANCE

RD1 Graph.jpg
Asset 1 (1).png

RD2



FEATURES

• Max Flow : 1.7 l/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 97 x 77 x 59mm

• Connector Size :15/8mm OD

MATERIALS

Diaphragm: SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

PERFORMANCE

RD2 Graph.jpg

RD3

Asset 1 (1).png


FEATURES

• Max Flow : 0.44 G/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 3.8" x 3.0" x 2.3"

• Connector Size :0.59"/0.3" OD

MATERIALS

Diaphragm: SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

PERFORMANCE

RD3 Graph.jpg
Asset 1 (1).png

RD5



FEATURES

• Max Flow : 1.32 G/min

• Max Vacuum : 200 mbar

• Max Pressure : 2.0 bar

• Size : 3.8" x 3.0" x 2.3"

• Connector Size :0.59"/0.3" OD

MATERIALS

Diaphragm: SANTROPENE

Head : POLYPROPYLENE

• 12V • BLDC

• 24V

PERFORMANCE

RD5 Graph.jpg
Asset-8-compressor (1).png

VISCOUS PUMPING

The patented Rotary Diaphragm technology has the unique capability of being able to pump thick liquids such as peanut butter, custard and hand gels.

DIAPHRAGM PUMPS

PERFORMANCE OVERVIEW

FLOW

0.11 - 1.58 G/MIN

WHY CHOOSE DIAPHRAGM?

The major advantage of the diaphragm pump is that the pumping chamber is totally sealed and, therefore, does not require a sliding seal between moving parts. Vacuum and pressure are produced by the flexing of the diaphragm back and forth in the chamber.

DOWN TO 350 MBAR ABS

VACUUM

PRESSURE

UP TO 2 BAR

D3 DC


D3 DC.jpg

FEATURES

• Max Flow : 0.79 G/min

• Max Vacuum : 350 mbar

• Max Pressure : 2.0 bar

• Size : 2.9" x 1.1" x 2.0"

• Connector Size : 0.15"

MATERIALS

Diaphragm : EPDM

Head : NYLON

• 12V • BLDC

• 24V

PERFORMANCE

D3 DC graph.png

D5 SE & D6 SE


D5 & D6.jpg

FEATURES

• Max Flow : 1.58 G/min

• Max Vacuum : 190 mbar

• Max Pressure : 2.0 bar

• Size : 3.7" x 3.1" x 1.8"

• Connector Size : 0.23"

MATERIALS

Diaphragm : EPDM

Head : NYLON

• 12V • 110V • BLDC

• 24V • 230V

PERFORMANCE

D5 graph.png

DL04



FEATURES

• Max Flow : 0.11 G/min

• Max Lift : 6.5ft

• Max Head : 65ft

• Size : 2.8" x 1.1" x 2.0"

• Connector Size : 0.15"

MATERIALS

Diaphragm : EPDM

Head : NYLON

• 12V • BLDC

• 24V

PERFORMANCE


DL2



FEATURES

• Max Flow : 0.11 G/min

• Max Lift : 16ft

• Max Head : 65ft

• Size : 3.9" x 1.6" x 3.9"

• Connector Size : 0.15"

MATERIALS

Diaphragm : EPDM

Head : NYLON

• 12V • 110V

• 24V • 230V

PERFORMANCE

Asset-10-compressor (3).png

The patented Rotary Diaphragm pumping principle that the RD Series uses are self priming, making the pump installation a lot easier and can even be mounted upside down.
